Powerful NDT Testing 370nm Handheld IP65 UV LED Lamps TMUV45B/TMUV80B
Introduction
Portable UV LED lamps adapts most advantage UV LED technology. This UV LED lamps features powerful TMUV Series a convenient white light LED to quickly switch between fluorescent inspection and flaw location. Every handheld NDT lamp is strictly tested by our senior engineer to ensure that the spectrum strictly focuses on 365-370nm and equipped with UV filter.
Features
100% solid state circuit ensures working properly in strong magnetic field
Switch function between UV light and White light
Extremely large coverage area of up to 6 inches (15 cm), with a minimum UV-A intensity of 2,000 μW/cm2
Unique mechanical cooling system keeps LEDs cool to maintain optimum light output during extended use
Rugged, modular construction allows for easy field serviceability.
Compliant with conformation to EMC and IEC81
Technical data
| Product’s Name | Handheld UV LED lamps | |
| Part No | 9031001 | 9031002 |
| Brand | TMTECK | TMTECK |
| Model type | TMUV-80B | TMUV-45B |
| Power Source | 1,220v ; 2 ,12V LI battery | |
| UV lamp Intensity at 38CM | 8000uw/cm2 | 4500uw/cm2 |
| Coverage area at 38cm | 17cm dia | 25cm dia |
| Visibale Light | 0.2foot-candles (2.1lux) | 0.1foot-candles (1lux) |
| Peak Wavelength | 365-370nm | 365-370nm |
| Power waste | less than 10W | less than 10W
|
| Weight | 700g(with battery) | |
| Battery | Li-ion battery | |
| Working hours when full charging | 4.5 working hours | |
| Power supply | 12V/DC AC100-240V 1A | |
| IP grade | IP65 | |
